Item

Function

Test   conditions and requirements

Rated   voltage

6V

Operating   voltage

5.5V—7V

Rated   current

3mA

DC Resistance

18Ω

Bleeding time

＜3 Sec.

Fill 50K   Pa gas into a   100 ml bottle to test the deflation time of the product.

The maximum pressure applied

55Kpa

See   specification for details

Insulation class

A

Air leakage requirement

＜15mmHg/Min.

Service life

300000 Cycles

Operating environment

Temperature：0~45℃

Humidity：75%

Fluid usage

Air

Weight

35.7g
