Item

Function

Test   conditions and requirements

Rated   voltage

12V

Operating   voltage

10.8V—13.2V

Rated   current

3.83mA

DC Resistance

46Ω

Bleeding time

＜3 Sec.

Fill50K Pa   gas into   100 ml bottle to test the deflation time of the product.

The maximum pressure applied

55Kpa

See   specification for details

Insulation class

A

Air leakage requirement

＜15mmHg/Min.

Service life

300000 Cycles

Operating environment

Temperature：0~45℃

Humidity：75%

Fluid usage

Air

Weight

18g
