Item

Function

Test conditions and requirements

Rated   voltage

12V

Operating   voltage

10.8V—13.2V

Rated current

0.333mA

DC   Resistance

4Ω

Bleeding   time

＜3 Sec.

Fill 50K Pa gas into 100 ml bottle to test the deflation   time of the product.

The maximum pressure applied

55Kpa

See   specification for details

Insulation   class

A

Air leakage   requirement

＜15mmHg/Min.

Service   life

300000 Cycles

Operating   environment

Temperature：0~45℃

Humidity：75%

Fluid usage

Air

Weight

15.5g
