Item

Function

Test conditions and requirements

Rated   voltage

12V

Operating   voltage

10.8V—13.2V

Rated current

460mA

Load   current

530mA

Fillwith   50KPa gas into 100CC   bottle to   test the working current of the product.

Air mass flow

8.0L

Pressure

＞80Kpa

Noise

65dB

Fill with 50Kpa gas into 100CC bottle to test   the product's working noisy（Ambient   noise ≤ 45dB）

Service   life

Carbon   brush

＞350H

Metal   brush

＞100H

Operating   environment

Temperature：≤50°C

Humidity：75%

Using the   fluid

Air

Monomer   weight

131g
